6240B DC Voltage Current Source/Monitor Operation Manual
2.2.2 Setting Limit Values
2-20
2.2.2 Setting Limit Values
Press LIMIT to set the limit value setting screen.
To change the limit values, follow the procedure described in Section 2.2.1, "Setting Source Value." How-
ever, the range cannot be set. (The optimum range is always displayed.)
The HI and LO limit values have two settings. This section describes the difference between them. ("HL
value" refers to HI limit value, and "LL value" refers to LO limit value.)
The setting function is changed using MENU, SOURCE, and LMT Input.
Balance setting
1. Press LIMIT.
The cursor appears on the HL value.
2. Move the cursor to 3.
To Next Page
