ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
5.2.5 Source Function
5-30
5.2.5.4 Source Range
1. Source range
• The source value (pulse value) for the DC source, pulse source or low-resistance measurement
pulse source mode is output in the displayed range.
• The range of the bias, base, start and stop values for the sweep source mode is decided depend-
ing on whether the sweep range is set to Auto or fixed as below regardless of the set or dis-
played value.
Set the sweep range according to the parameters B) SWEEP, 2) SWP Range in the menu.
2. Range to be set when the sweep range is Auto
3. Ranging during sweep
The period time may be extended if a range change occurs while sweeping. For more information on
the sweep operation in this case, see Table 5-5, "Operations in DC Sweep Source Mode" or Table 5-6,
"Operations in Pulse Sweep Source Mode."
If the period time is extended, the TpALM indicator illuminates.
Sweep range setting Range
Fix Fixes to the range that can output the maximum value
of all setting values.
The range is not changed while sweeping.
Auto Sets every setting value to the optimum range so the
number of enabled digits is the largest.
If there are setting values in different ranges, the
range changes during the sweep.
Source function Setting value Range
Voltage source 0 mV  |Vs|  320.00 mV 300 mV
320.00 mV < |Vs| 3.2000 V 3 V
3.2000 V < |Vs| 15.000 V 15 V
Current source 0 A |Is| 32.000 A 30 A
32.000 A < |Is| 320.00 A 300 A
320.00 A < |Is| 3.2000 mA 3 mA
3.2000 m A < |Is| 32.000 mA 30 mA
32.000 mA < |Is| 320.00 mA 300 mA
320.00 mA < |Is| 1.0000 A 1 A
1.0000 A < |Is|  4.0000 A 4 A
