6240B DC Voltage Current Source/Monitor Operation Manual
2.2 Basic Operation
2-12
2.2 Basic Operation
This section describes the following items:
• Setting the source value
• Setting the limit values
• How to use the menu and basic measurement functions
NOTE: The operation procedures listed permit the settings to be made in the shortest time. If the display differs
from the one shown, repeat the procedure from the beginning.
2.2.1 Setting Source Value
2.2.1.1 Relation between Keys
The following figure shows the relation between keys
Figure 2-13 Relation between Keys
Cursor digit value
up and down
HOME screen
or
Range
up and down
Source and
measurement screen
Limit setting screen
Moves the cursor
Note: HOME screen refers to the screen
displaying a source value, a measured
value or limit values.
Returns to the
previous value
Applies
the value
Restores the
value
Direct input mode
Numeric value
(mantissa)
Unit
To Next Page
