ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
9.5 Supplementary Descriptions
9-13
9.5 Supplementary Descriptions
9.5.1 How to Calculate Accuracy for Current Source, Current Measurement and
Current Limiter
Example)Calculating the accuracy in current source of 3 mA (3 mA range) with resistance of 1 k
connected
The accuracy formula in the current source range of 3 mA is as follows:
The output voltage Vo is 3V. Therefore,
Accuracy = (% of setting + A + A  Vo / 1 V )
= (3 mA
 0.03 % + 800 nA + 30 nA  3 V / 1 V)
= 
1.79 A
Thus, the accuracy in current source of 3 mA (3 mA range) is specified between 2.9982 mA to 3.0018 mA.
NOTE: Vo in the 1-day stability, current limiter and temperature coefficient for voltage source all indicates volt-
age between output terminals.
Range
Accuracy
(% of setting + A + AVo / 1 V )
Current source 3 mA 0.03 + 800 nA + 30 nA
