6240B DC Voltage Current Source/Monitor Operation Manual
1.4.4 Power Cable
1-9
1.4.4 Power Cable
CAUTION:
1. Use a power cable that conforms to the power outlet voltage and type. However, for use outside of Japan, use
only a power cable approved for the respective country.
2. To prevent electric shock, connect the power cable to an outlet with a ground terminal. If an extension cable
without a ground terminal is used, the protective ground feature will be rendered ineffective.
3. Be sure to set the POWER switch on the front panel to OFF before connecting the power cabl.
Figure 1-4 Power Cable
Into AC power outlet
Ground pin
3-pin power cable
