6240B DC Voltage Current Source/Monitor Operation Manual
5.2.16 Self Test
5-72
2. Self-test execution by manual operation or turning the power ON
When executing the self test by manual operation, select the parameters M) SYSTEM and 5) Self Test
in that order on the menu screen and press ENTER.
Press and then press or to select the parameters "Self Test" and "Dsp/Key Tst."
Figure 5-18 Self-Test Operation
Verify the error detected
Revision display
PASS
FAIL
PASS (no error)
Displayed in accordance
with the key pressed
• All the panels
light up (including
indicators).
• Buzzing approx. 1
second
Self test in progress
Power
ON
INC: Rotate the rotary knob clockwise.
DEC: Rotate the rotary knob counterclockwise.
To Next Page
