5.2.16 Self Test
5-71
45 221
Low Limit 300 mV +FS LL 0.3V +FS
b
256
46 222
Low Limit 300 mV -FS LL 0.3V -FS
512
47 223
Low Limit 3 V +FS LL 3V +FS
1024
48 224
Low Limit 3 V -FS LL 3V -FS
2048
53 225
Low Limit 15 V +FS LL 15V +FS
4096
54 226
Low Limit 15 V -FS LL 15V -FS
8192
55 231
IM 30 A ZERO IM 30A Zero
d
1
56 232
IM 300 A ZERO IM 300A Z
2
57 233
IM 3 mA ZERO IM 3mA Zero
4
58 234
IM 30 mA ZERO IM 30mA Zero
8
59 235
IM 300 mA ZERO IM 300mA Z
16
62 236
IM 1 A ZERO IM 1A Zero
32
64 237
IM 4 A ZERO IM 4A Zero
64
65 241
ISIM 30 A +FS IS 30A +FS
e
1
66 242
ISIM 30 A -FS IS 30A -FS
2
67 243
ISIM 300 A +FS IS 300A +FS
4
68 244
ISIM 300 A -FS IS 300A -FS
8
69 245
ISIM 3 mA +FS IS 3mA +FS
16
70 246
ISIM 3 mA -FS IS 3mA -FS
32
71 247
ISIM 30 mA +FS IS 30mA +FS
64
72 248
ISIM 30 mA -FS IS 30mA -FS
128
73 249
ISIM 300 mA +FS IS 300mA +FS
256
74 250
ISIM 300 mA -FS IS 300mA -FS
512
79 251
ISIM 1 A +FS IS 1A +FS
1024
80 252
ISIM 1A -FS IS 1A -FS
2048
83 253
ISIM 4 A +FS IS 4A +FS
4096
84 254
ISIM 4A -FS IS 4A -FS
8192
85 301
OVL detection check OVL Check
d
256
86 311
Sample hold check S/H Check
512
87 -
All the panels light ON Visual check
--
88 -
Buzzer Buzzer sound check
89 -
Panel key Visual check
(*1) TER? command response register and data
In the error register (ERR?) the following bits are set.
• At power ON; bit 0
• In executing the self-test; bit 1
Table 5-19 Self-Test Items (2/2)
Error code Description
Execution method
Message
TER register (*1)
Power ON *TST?
Key
operation
Register Data
