6240B DC Voltage Current Source/Monitor Operation Manual
9.3 Setting Time
9-10
Voltage measurement input resistance: 1 G or higher
Voltage measurement input leak current:
1 nA or lower
GPIB: Compliant with IEEE-488.2-1987
Interface function;
SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT1, C0, E2
Connector; Amphenol 24 pin
USB: USB 2.0 Full-speed
Connector; Type B
External control signal: TRIGGER IN, INTERLOCK, OPERATE IN,
OPERATE OUT, SYNC OUT
Connector; BNC
9.3 Setting Time
Minimum pulse width: 50 s
Minimum step (repeat) time: Under fixed source/measurement range, integration time of 100 s, the
minimum measurement or source delay time, calculation function
OFF, and voltage/current measurement
Source delay time:
Period (pulse cycle):
Measurement Memory mode Minimum step time
OFF - 0.5 ms
BURST 2 ms
ON NORMAL
10 ms
OFF
Setting range Resolution
*7
Setting accuracy
0.030 ms to 60.000 ms 1 s
60.01 ms to 600.00 ms 10 s (0.1 % + 10 s)
600.1 ms to 6000.0 ms 100 s
6001 ms to 59998 ms 1 ms
Setting range Resolution
*7
Setting accuracy
0.500 ms to 60.000 ms 1 s
60.01 ms to 600.00 ms 10 s (0.1 % + 10 s)
600.1 ms to 6000.0 ms 100 s
6001 ms to 60000 ms 1 ms
