ADCMT 6240B - Calibration Procedure

6240B DC Voltage Current Source/Monitor Operation Manual
8.5 Calibration Procedure
8-9
Figure 8-6 Calibration Procedure (4)
DMM data
acquisition
XD DMM data DMM data input *Out-of-range setting results in a parameter error.
Current source/limiter
calibration
[Calibration mode setting]
[Range setting]
Enters the DMM data input mode.
Within
tolerance range?
DMM data
acquisition
XD DMM data DMM data input *Out-of-range setting results in a parameter error.
DMM data
acquisition
Checks the calibration result.
Calibration result data
save and display
DMM data
acquisition
Calibration result data
save and display
IS mode IL-Hi mode IL-Lo mode
