6240B DC Voltage Current Source/Monitor Operation Manual
5.2.9 Source and Measurement Timing
5-52
5.2.9.3 Integration Time and Measurement Time
The measurement time (Tm) is calculated from the integration time (Tit) and the internal processing time
(Tk) according to the following formula:
Tm = Tit + Tk
The integration time (Tit) can be selected between 100 s and 200 ms.
The internal processing time (Tk) is determined by the source mode and memory store mode settings as
below.
When the memory store mode is OFF or Normal-ON, the following processing times are added by NULL
calculation, scaling calculation, Max/Min calculation, and comparator calculation.
NULL calculation ON: Approx. 0.2 ms
Scaling calculation ON: Approx. 1 ms
Max/Min calculation ON: Approx. 1 ms
Comparator calculation ON: Approx. 15 ms
In measuring resistance: Approx. 1 ms
(Example) DC source mode, integration time: 1 PLC (50 Hz), memory store: Normal-ON,
NULL calculation: ON, scaling calculation: ON, Max/Min calculation: ON,
comparator calculation: ON
In these conditions, the measurement time is calculated as follows:
Tit = 20 ms
Tk = 4 + 0.2 + 1 + 1 + 15 = 21.2 ms
Tm = Tit + Tk = 41.2 ms
5.2.9.4 Auto Range Delay
The auto range delay function is used when a capacitive load (C
L
) is measured by voltage source current
measurement (VSIM).
When voltage is applied to C
L
and current is measured in Auto range, after C
L
is charged the current value
drops and the measurement range decreases. This function delays the measurement for the temporal
response in the current value that occurs when the measurement range is switched.
Source mode Memory store Tk [ms]
DC
Pulse
OFF Approx. 4
Normal-ON Approx. 4
Burst-ON Approx. 1
DC Sweep
Pulse Sweep
OFF Approx. 5
Normal-ON Approx. 5
Burst-ON Approx. 1
