6240B DC Voltage Current Source/Monitor Operation Manual
2.2.1 Setting Source Value
2-13
2.2.1.2 Setting Source Value Using Cursor Keys/Rotary Knob (with FIT Indicator
OFF)
1. Change the source value using the cursor keys ( , ) and the UP/DOWN keys ( , ) or
the rotary knob ( ).
and keys move the cursor (blinking) position left and right. , keys, or rotary
knob can change the value indicated by the cursor.
The following figures show the setting procedure.
Setting numeric values
1. Press .
The cursor moves to the left.
2. Press or rotate one click clockwise.
The figure indicated by the cursor increases by one increment.
Cursor (blinking)
Cursor (blinking)
Cursor (blinking)
