ADCMT 6240B - Page 265

6240B DC Voltage Current Source/Monitor Operation Manual
9.3 Setting Time
9-11
Pulse width:
Measurement delay time:
Hold time:
Auto range delay time:
Setting range Resolution
*7
Setting accuracy
0.050 ms to 60.000 ms 1 s
60.01 ms to 600.00 ms 10 s (0.1 % + 10 s)
600.1 ms to 6000.0 ms 100 s
6001 ms to 59998 ms 1 ms
Setting range Resolution
*7
Setting accuracy
0.050 ms to 60.000 ms 1 s
60.01 ms to 600.00 ms 10 s (0.1 % + 10 s)
600.1 ms to 6000.0 ms 100 s
6001 ms to 59998 ms 1 ms
*7: The setting resolution is determined by the period time
resolution.
Setting range Resolution Setting accuracy
1 ms to 60000 ms 1 ms (2 % + 3 ms)
Setting range Resolution Setting accuracy
0 ms to 500 ms 1 ms (2 % + 3 ms)
