6240B DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-28
1) Start Value
Linear sweep start value In Linear mode
Numeric
VS +000.00 mV to 15.000 V
IS +00.000 A to 4.0000 A
2) Stop Value
Linear sweep stop value In Linear mode
Numeric
VS +000.00 mV to 15.000 V
IS +00.000 A to 4.0000 A
3) Step Value
Linear sweep step value In Linear mode
Numeric
VS 000.01 mV to15.000 V
IS 00.001 A to4.0000 A
1) Level Value
Fixed sweep level value In Fixed mode
Numeric
VS +000.00 mV to15.000 V
IS +00.000 A to4.0000 A
2) Sample Cnt
Fixed sweep sample count In Fixed mode
Numeric
1 to 8000
1) Sweep Adr
Random sweep start address/stop address In Random mode
Numeric
0 to 7999
* Use [SEL] to switch between Start and Stop.
1) First Val
2-slope linear sweep first value In Linear 2 mode
Numeric
VS +000.00 mV to15.000 V
IS +00.000 A to4.0000 A
2) Middle Val
2-slope linear sweep middle value In Linear 2 mode
Numeric
VS +000.00 mV to15.000 V
IS +00.000 A to4.0000 A
3) Last Val
2-slope linear sweep last value In Linear 2 mode
Numeric
VS +000.00 mV to15.000 V
IS +00.000 A to4.0000 A
4) Step1 Val
2-slope linear sweep Step 1 value In Linear 2 mode
Numeric
VS 000.01 mV to15.000 V
IS 00.001 A to4.0000 A
5) Step2 Val
2-slope linear sweep Step 2 value In Linear 2 mode
Numeric
VS 000.01 mV to15.000 V
IS 00.001 A to4.0000 A
6) Bias Value
Sweep bias value
Numeric
VS +000.00 mV to15.000 V
IS +00.000 A to1.0000 A
7) PSW Base
Pulse sweep base value
Numeric
VS +000.00 mV to15.000 V
IS +00.000 A to1.0000 A
C) SWEEP VAL
Category level
Select level Input/Run level
Parameter
type
(a)
(b)
