6240B DC Voltage Current Source/Monitor Operation Manual
4.2.6 MENU Key (Parameter Setting)
4-10
COMPUTE Set the calculation-related parameters.
Compare SW Switches the comparator calculation ON or OFF.
On: Executes the comparator calculation.
The calculation result is reflected on the indicator,
the header of GPIB data output and the status byte.
HI: High value < Measurement data
GO: Low value ï‚£ Measurement data ï‚£ High value
LO: Measurement data < Low value
Off: Turns OFF the comparator calculation.
Scaling SW Switches the scaling calculation ON or OFF.
Scaling calculation =
On: Executes the scaling calculation.
The MATH indicator goes ON.
Off: Turns OFF the scaling calculation.
Max/Min SW Switches the MAX/MIN calculation ON or OFF.
On: Executes the MAX/MIN calculation.
The MAX, MIN, AVE, and  indicators go ON.
Off: Turns OFF the MAX/MIN calculation.
View Mx/Mn Displays the MAX/MIN calculation data.
Sample Number of measurement data
Maximum Maximum measurement data value
Minimum Minimum measurement data value
Average Measurement data average value
Total Total measurement data value
CONST Sets calculation constants.
High Value Sets the upper limit value of the comparator calculation.
Low Value Sets the lower limit value of the comparator calculation.
SCL Val_A Sets constant A for the scaling calculation.
SCL Val_B Sets constant B for the scaling calculation.
SCL Val_C Sets constant C for the scaling calculation.
Null Value Sets the NULL value when the NULL calculation is ON.
Not displayed when the NULL calculation is OFF.
Constant A
(Measurement value) - Constant B
ï‚´ Constant C
To Next Page
