ADCMT 6240B User Manual

6240B DC Voltage Current Source/Monitor Operation Manual
5.1.2 Remote Sensing (2-Wire/4-Wire Connection)
5-3
NOTE: The maximum remote sensing voltage (tolerable voltage difference between OUTPUT and SENSE) is
 1 V at both HI and LO sides.
To satisfy the specified accuracy, maintain the following restriction for r
1 to r4.
r
1, r2  1 V/Io [  ]
(Io: Output current)
r3, r4   220 k  [  ]
(Vos = r
1Io, r2Io)
(Example) If Io = 0.5 A
r
1, r2  1 V/0.5 A = 2 
r1, r2 = 2 
then,
r3, r4   220 k  = 2.2 
10  V
Vo s
10  V
1 V
