6240B DC Voltage Current Source/Monitor Operation Manual
5.2.9 Source and Measurement Timing
5-50
2. Voltage source
The settling time (Ts) of the 6240B is defined by the voltage source value (Vs), the current limit value
DIL (digits), and the settling time setting (Fast/Slow), as shown below.
Set the measurement delay (Td) to Ts or over.
• Fast mode
Current limiter range is 300 A to 4 A:
Ts=70+(Vs  30000/DIL) [s]
Current limiter range is 30 A:
Ts=(70+(Vs  30000/DIL))  3 [s]
•Slow mode
Current limiter range is 300 A to 4 A:
Ts=200+(Vs  100000/DIL) [s]
Current limiter range is 30 A:
Ts=(200+(Vs  100000/DIL))  2 [s]
(Example) Ts values when current limiter range is 300 A to 4 A Unit [s]
Vs [V]
Current limiter setting value DIL [digit]
500 1000 2000 3000
Fast Slow Fast Slow Fast Slow Fast Slow
1 130 400 100 300 85 250 80 233
3 250 800 160 500 115 350 100 300
5 370 1200 220 700 145 450 120 367
10 670 2200 370 1200 220 700 170 533
15 970 3200 520 1700 295 950 220 700
