6240B DC Voltage Current Source/Monitor Operation Manual
6.6 Data Output Format (Talker Format)
6-19
1. Header
The header is not output when the header setting is OFF.
• Main header
DV: DC voltage measurement
DI: DC current measurement
RM: Resistance measurement (resistance value display)
EE: No data in the specified measurement memory
• Sub header
Sub header
Main header
U: High limit detected
B: Low limit detected
O: Range over
Z: For resistance measurement, the voltage source value is set to 0 (zero).
F: For resistance measurement, the current source value is below 20 digits or
the current measurement value is below 200 digits.
E: Calculation error (scaling function or total function)
H: The comparator calculation result is HI.
G: The comparator calculation result is GO.
L: The comparator calculation result is LO.
C: Scaling calculation data
N: NULL calculation data
: Others (space output)
High
Priority
Low
