6240B DC Voltage Current Source/Monitor Operation Manual
6.6 Data Output Format (Talker Format)
6-21
3. String delimiter
A string delimiter ", " (comma) is output to specify a boundary in a data stream.
It is used when multiple data sets are read out from the measurement data memory.
4. Block delimiter
A block delimiter is output to specify the end of a unit of data.
The type of block delimiters can be specified by the following commands:
Range over 9.99999 E+35 9.99999 E+35
IS is below 20 digits or
IM is below 200 digits. *1
+9.99999 E+34 +9.99999 E+34
VS is set to 0 (zero). *1 +9.99999 E+33 +9.99999 E+33
Scaling error 9.99999 E+32 9.99999 E+32
TOTAL error 9.99999 E+31 9.99999 E+31
No data exists at recall. *2 +8.88888 E+30 +8.88888 E+30
*1: This may occur in resistance measurement.
*2. Data does not exist when the measurement buffer memory data is read out.
Block delimiter Command Default
CR LF+EOI DL0
LF DL1
EOI DL2
LF+EOI DL3
(EOI is a GPIB function. It is not available on USB.)
Measurement function
Unit display
Decimal point and unit
symbol form
Exponent form
Mantissa part
Exponent
part
Mantissa part
Exponent
part
