6240B DC Voltage Current Source/Monitor Operation Manual
9.1 Source and Measurement
9-2
Voltage/current limiter (compliance) range:
Accuracy:
Includes calibration accuracy, 1-day stability, temperature coefficient, and linearity.
1-day stability: At constant power and load
Temperature coefficient: At temperature of 0 to 50 C
Maximum setting range Setting resolution
*1
Voltage limiter 0 V to 320 mV 100 V
320.1 mV to 3.2 V 1 mV
3.201 V to 15 V 10 mV
Current limiter 100 nA to 32 A 10 nA
32.01 A to 320 A 100 nA
320.1 A to 3.2 mA 1 A
3.201 mA to 32 mA 10 A
32.01 mA to 320 mA 100 A
320.1 mA to 1 A 1 mA
1.001 A to 4 A 1 mA
*1: Where, (Hi limit value - Lo limit value) 60 digits
Range
Accuracy 1-day stability Temperature coefficient
(% of setting + V) (ppm of setting + V)/C
Voltage source 300 mV 0.02 + 150 V0.01 + 70 V15 + 15 V
3 V 0.02 + 350 V 0.01 + 200 V15 + 30 V
15 V 0.02 + 3 mV
*2
0.01 + 2 mV 15 + 300 V
Voltage limiter 300 mV 0.10 + 1 mV
*3
0.05 + 200 V 100 + 50 V
3 V 0.05 + 8 mV
*3
0.01 + 1 mV 15 + 100 V
15 V 0.07 + 80 mV
*3
0.01 + 10 mV 15 + 1 mV
*2: In the 15 V range, 200 V is added per 0.1 V remote sensing voltage.
*3: Voltage limiter additional error: When the Hi limit value is set to a negative value and the Lo limit value is
set to a positive value, an error of 0.1 % of setting is added.
