6240B DC Voltage Current Source/Monitor Operation Manual
A-5
Hardware error 401 Fan Stopped Fan stopped
402 Over Heat Overheat
403 Source Unit Source unit circuit error
404 Over Load Overload
Source/measurement error - OverRange Measurement over range
- HiLimit RM/LoLimit RM Resistance measurement in limit detection status.
- VSource=0 Resistance measurement with source value = 0
- Count Few IS is below 20 digits or IM is below 200 digits.
- SCL Over Scaling over
- Over Total value error
Operation 801 Over Step 8000 < Number of sweep steps
811 Power Over Source value exceeding 1 A in DC
812 Duty Over Pulse Duty limit over
821 Tw too Long Tw value over against pulse
822 Tp < Tds Timer condition error (Not Tp > Tds + 300 s)
823 Tp < Td Timer condition error (Not Tp > Td + 300 s)
824 Tp < Tds+Tw Timer condition error (Not Tp > Tds + Tw + 300 s)
825 Td < Tds Timer condition error (Not Td > Tds)
828 600ms < Tp S/H timer condition error (Not Tp 600 ms)
831 Interlock Disabled by interlock
855 CAL data Calibration data error
Remote command error -102 Cmd Syntax Command syntax error
-113 Cmd Undefine Command undefined
-200 Cmd Exec Execution error (Command currently not executable)
-222 Out of Range The input value is out of range.
USB communication 140 CPU Comm USB/SCI communication error (illegal code received)
141 ILL Comm USB/SCI communication error (another code received)
150 USB error USB communication error
Table A-2 Error Message List (3/3)
Classification Error code Message Description
