6240B DC Voltage Current Source/Monitor Operation Manual
A-8
1. Measurement execution time
Conditions: Source range; fixed
Measurement range; fixed, Trigger mode; external trigger,
Number of measurement digits; 5
1
/
2
digits
Integration time; 100 s, Measurement delay; 0.3 ms, Source delay; 30 s
Period; 2 ms, Pulse width; 1 ms
Header; OFF, Block delimiter; EOI (DL2)
• Time from measurement by trigger input (*TRG) to completion of data output to GPIB/USB
• Time from measurement by source command reception and trigger input (*TRG) to completion
of data output to GPIB/USB
In the DC or pulse source mode
• The time from measurement by spot command reception (measurement trigger after setting the
source value for the setting source function) to completion of data output to GPIB/USB
In the DC or pulse source mode
Source value condition
GPIB
execution
time
USB
execution
time
In DC or pulse source 5 ms 18 ms
When the sweep start value is output 9 ms 19 ms
When the sweep step value is output 6 ms 18 ms
Source Command
GPIB
execution
time
USB
execution
time
Voltage source SOV<data> (<data>: 1 character) 8 ms 23 ms
Current source SOI<data> (No unit, <data>: 3 characters) 8 ms 24 ms
Source Command
GPIB
execution
time
USB
execution
time
Voltage source G<data> (<data>: 1 character) 9 ms 18 ms
Current source G<data> (No unit, <data>: 3 characters) 10 ms 20 ms
