6240B DC Voltage Current Source/Monitor Operation Manual
2.1.2 Screen Display (Annotations)
2-9
11. Right status indicators RMT : Remote control
MA: Addressed as Lister or Talker via GPIB
SRQ: SRQ is being transmitted.
MAX, MIN, AVE, :
MAX/MIN calculation is ON.
: (Not in Use)
ERR: An error log is generated.
CAL: The calibration mode is ON.
OPR: Illuminates or extinguishes depending on the output
status.
Operate: ON
Suspend: Blinks
Standby: OFF
: When the comparator calculation is ON, either one of
these three indicators goes ON depending on the
results.
LMT: The measured value is in the limit status.
OSC: (Not in use)
RVS: (Not in use)
BUSY: (Not in use)
SHIFT: The shift mode is ON.
12. m indicator The low-resistance measurement pulse mode is ON.
