6240B DC Voltage Current Source/Monitor Operation Manual
3.2 Battery Charge and Discharge Test
3-5
Test conditions are described below.
Charge test: Charge with a constant current of 500 mA. After the voltage reaches 1.45 V, charge with
a constant voltage. When the current reaches 100 mA or below, stop charging.
Charge test condition example
Source mode
Source current
Limit value
Suspend voltage
Period
Integration time
Measurement range
Memory
Comparator
External control signal
Remote sensing
:
:
:
:
:
:
:
:
:
:
:
DC
500 mA
HL value; 1.45 V
LL value; 0.95 V
HiZ; 1.20 V
1 s
200 ms
3 V range fixed
NORMAL, STORE ON
ON
Lower limit value; 100 mA
OPERATE OUT; STBY IN
COMPLETE OUT; Comp-LO
Pulse width: 100 s
4-wire
