6 Carefully pull off the ferret from the wires and keep it in a
safe place. Then pull out the FLL board.
7 Insert the new FLL board. Fit the wires through the holes
and the Ferret.
8 Put the wires into the released contacts using the
tweezers.
Order of wires (left to right):
9 Reinstall the lamp as described in “Exchanging the
Lamp" on page 147.
FLL Board
Ferret
FLL Board
Ferret
green
empty
brown
yellow
white
