Introduction to the Control Module 9
1100 Series FD Reference Manual 313
Press F6 key (Select). Here you can add additional on-line signals (maximum
are 3). Additional signals could be also pressure or temperature signals from
other modules. Use the Right/Left arrows to switch between Available and
Selected Signals. Use the F8 key (Move) to enter available signals into the box
for selected signals or vice versa.
Method screens
Use ESC to return to the Analysis screen. Use the F3 key (Method) to view the
parameters in a method and F8 key (Save As) to save the method in the
mdodule(s). The PC-Card key is only active when a PCMCIA card is inserted in
the control module.
