Agilent Technologies 8753ET Service Guide

2-76 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Figure 2-42 Test Port Phase Compression Test Setup
Figure 2-43 Test Port Phase Compression Test Setup for 75Ω Analyzers
2. Press .
3. Press .
4. Press
.
5. Press (or next CW frequency).
Preset
IF BW
10 x1
Meas
INPUT PORTS
B/R
Format
PHASE
Sweep Setup
SWEEP TYPE MENU
POWER SWEEP
Start −10
x1 Marker −10 x1
∆
MODE MENU
∆
REF = 1
Sweep Setup
CW FREQ
300
k/m
