13-44 Chapter 13

Replaceable Parts

Replaceable Part Listings

8753ET/ES: Rear Panel Assembly, Option 1D5

Ref.

Desig.

Option HP/Agilent

Part Number

Qty Description

1 1D5 1250-1859 1 ADAPTER-COAX

2 1D5 0515-0374 1 SCREW-MACHINE M3.0×10 CW-PN-TX

3 1D5 3050-1546 1 WASHER-FLAT .505ID NY

4 1D5 2190-0068 1 WASHER-LOCK .505ID

5 1D5 0590-1310 1 NUT-SPECIALTY 1/2-28

6 1D5 0515-0430 1 SCREW-MACHINE M3.0×6 CW-PN-TX

7 1D5 08753-00078 1 BRACKET-OSC BD

8 6960-0027 2 HOLE PLUGS

A26 1D5 08753-60158 1 BD ASSY-HIGH STABILITY FREQ REF

W30 1D5 8120-6458 1 RP INTERFACE (A16J3) to HIGH-STABILITY FREQ

REF (A26J1)
