Chapter 2 2-87
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
Use this section of the manual if you are performing system verification and/or
performance tests on an 8753ET analyzer. If your instrument is an 8753ES, turn to
“Agilent 8753ES System Verification and Performance Tests” on page 2-5.
System Verification Cycle and Kit Re-certification
Agilent Technologies recommends that you verify your network analyzer measurement
system every six months. Agilent Technologies also suggests that you get your verification
kit re-certified annually. Refer to the HP/Agilent 85029B 7-mm Verification Kit Operating
and Service Manual for more information.
Check to see how the verification kit floppy disk is labeled:
• If your verification disk is labeled HP/Agilent 8753D, HP/Agilent 8753E,
HP/Agilent 8753ES, or HP/Agilent 8753ET Verification Data Disk, you may
proceed with the system verification.
• If your verification disk is not labeled as indicated above, you may send your
HP/Agilent 85029B 7-mm verification kit to the nearest service center for
recertification, which includes a data disk that you can use with the 8753ET.
8753ET System Verification
This system verification consists of three separate procedures:
1. “Initialization” on page 2-88
2. “Enhanced Response Calibration” on page 2-89
3. “Device Verification” on page 2-91
Analyzer warm-up time: 30 minutes
Required Equipment
Description HP/Agilent Model Number
Calibration Kit: 7-mm 85031B
Verification Kit: 7-mm 85029B
Test Port Extension Cable Set: 7-mm 11857D
Adapters (2): Type-N (m) to APC-7 (from cal kit) 85032B or 11525A
Printer: HP ThinkJet/DeskJet/LaserJet
