13-36 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ET/ES: Front Panel Assembly, Outside
Ref.
Desig.
ET/ES Option HP/Agilent
Part Number
Qty Description
1 ES 08753-80168 1 OVERLAY, LOWER FRONT PANEL
1 ES 075 08753-80170 1 OVERLAY, LOWER FRONT PANEL
1 ES 014 08753-80198 1 OVERLAY, LOWER FRONT PANEL
1 ET 08753-80218 1 OVERLAY, LOWER FRONT PANEL
2 ES 08753-60938 1
FP REPAIR KIT
a
a. Comes with casting, gasket, upper and lower overlays.
2 ES 075 08753-60940 1
FP REPAIR KIT
a
2 ES 014 08753-60942 1
FP REPAIR KIT
a
2 ET 08753-60941 1
FP REPAIR KIT
a
3 ET/ES 1510-0038 1 GROUND POST
4 ET/ES 2950-0006 1 NUT HEX 1/4-32
4 ET/ES 2190-0067 1 WASHER LK .256 ID
5 ET/ES 08753-40015 1 LINE BUTTON
6 ET/ES 08753-80216 1 OVERLAY, UPPER FRONT PANEL
7ES
08753-80208
1 NAMEPLATE, 8753ES, 30 kHz − 3 GHz
7ES006
08753-80205
1 NAMEPLATE, 8753ES, 30 kHz − 6 GHz
7 ET 08753-80207 1 NAMEPLATE, 8753ET, 300 kHz − 3 GHz
7 ET 006 08753-80204 1 NAMEPLATE, 8753ET, 300 kHz − 6 GHz
