2-72 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
12. Test Port Receiver Magnitude Compression
Perform this test to verify the magnitude compression/expansion of the analyzer’s test port
receivers. Power sweeps from low to high power are made at designated CW frequencies. A
reference measurement is made while the signal to the receiver is attenuated to avoid
compression. The attenuation is removed and compression is observed and measured.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Procedure
1. Connect the equipment as shown in Figure 2-40 (Figure 2-41 for 75Ω analyzers).
Frequency Range
Magnitude
a
a. With a 10 Hz IF bandwidth.
300 kHz to 3 GHz ≤0.42 dB
3 GHz to 6 GHz ≤0.76 dB
Description HP/Agilent Part or Model Number
Cable (2): 50Ω, APC-7 8120-4779
Step Attenuator 8496A Option 003 and Option H18
Additional Equipment for 75Ω Analyzers
Minimum Loss Pad (2) 11852B
Adapters (2): APC-7 to Type-N (f) 11524A
Cables (2): 50Ω, Type-N 24 inch 8120-4781
