13-26 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ES: Cables, Bottom
Ref.
Desig.
Opt
Type
a
a. nW = Wire Bundle (n is the number of wires in the bundle)
nR = Ribbon Cable (n is the number of wires in the ribbon)
SR = Semi-Rigid Coax Cable
HP/Agilent
Part Number
Qty Description
1 1400-0611 1 CABLE CLAMP
A21W1 1W 8120-6483 1 GRAY WIRE-TEST PORT 1 COUPLER (A21) to TEST
SET INTERFACE (A25TP1)
A22W1 1W 8120-6483 1 GRAY WIRE-TEST PORT 2 COUPLER (A22) to TEST
SET INTERFACE (A25TP2)
A24W1 3W 85047-60004 1 TRANSFER SWITCH (A24) to TEST SET
INTERFACE (A25J3)
W1 SR 08753-20952 1 SOURCE ASSY (A3W4) to TRANSFER SWITCH (A24)
W20 34R 8120-6890 1 CPU (A9J7) to MOTHERBOARD (A17J11)
W31 SR 08753-20288 1 TEST PORT 1 COUPLER (A21) to TRANSFER
SWITCH (A24)
W32 SR 08753-20289 1 TEST PORT 2 COUPLER (A22) to TRANSFER
SWITCH (A24)
W33 4W 08753-60221 1 LED (A23J1) to TEST SET INTERFACE (A25J2)
W37 26R 8120-8670 1 DISK DRIVE (A20) to CPU (A9J8)
W38 40R 8120-6882 1 TEST SET INTERFACE (A25J1) to MOTHERBOARD
(A17J2)
