7. Test Port Input Frequency Response
Power meter calibration is used to control the input to the analyzer’s receiver across its
frequency range. The network analyzer’s input receiver frequency response is measured
against this calibrated input.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Procedure
Power Meter Calibration for Test Port 1 from 300 kHz to 3 GHz
1. Zero and calibrate the power meter for the 8482A sensor.
2. Connect the equipment as shown in Figure 2-18.
Frequency Range
Input Frequency Response
a
a. At 0 dBm.
300 kHz to 3 GHz ± 1 dB
3 GHz to 6 GHz
b
b. Only for analyzers with Option 006.
± 2 dB
Description HP/Agilent Part or Model Number
Power Meter 436A/437B/438A or E4418B/4419B
Power Sensor 8482A
Cable: APC-7, 24-inch 8120-4779
Adapter: APC-7 to Type-N (f) 11524A
Additional Equipment for Option 006 Analyzers
Power Sensor 8481A
Additional Equipment for 75Ω Analyzers
Power Sensor 8483A Option H03
Cable: 75Ω, Type-N 8120-2408
Adapter: 75Ω, type-N (f) to type-N (f) 1250-1529
