Agilent Technologies 8753ET Service Guide

3-10 Chapter 3
Adjustments and Correction Constants
Source Pretune Correction Constants (Test 48)
Source Pretune Correction Constants (Test 48)
Analyzer warm-up time: 30 minutes.
This procedure generates pretune values for correct phase-locked loop operation.
1. Press
.
2. Observe the analyzer for the results of this adjustment routine:
• If the analyzer displays Pretune Cor DONE, you have completed this procedure.
• If the analyzer displays FAIL, refer to Chapter 7 , “Source Troubleshooting.”
Preset System
SERVICE MENU
TESTS
48 x1
EXECUTE TEST
YES
