4. Reflection Test Port Output Power Linearity
(Analyzers without Option 004)
This test verifies the analyzer’s test port output power linearity throughout the analyzer’s
frequency range. A power meter calibration sets the reference output power across the
analyzer’s frequency range. The network analyzer’s B-channel receiver is used to
determine power linearity after each change in output power.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Procedure
Power Meter Calibration
1. Zero and calibrate the power meter for one or both sensors.
2. Connect the equipment as shown in Figure 2-59.
Power Range
Power Level Linearity
a
a. Relative to −5 dBm from 300 kHz to 3 GHz
(6 GHz for Option 006).
−20 to −15 dBm ± 0.5 dB
−15 to 0 dBm ± 0.2 dB
0 to + 5 dBm ± 0.5 dB
Description HP/Agilent Part or Model Number
Power Meter 437A/438A or E4418B/4419B
Power Sensor 8482A
Attenuator: 20 dB, Type-N 8491A Option 020
RF Cable: 50Ω, Type-N, 24 inch 8120-4781
Additional Equipment for Option 006 Analyzers
Power Sensor 8481A
