13-32 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ET/ES: Cables, Rear
Ref.
Desig.
ET/ES Opt
Type
a
a. nW = Wire Bundle (n is the number of wires in the bundle)
nR = Ribbon Cable (n is the number of wires in the ribbon)
F = Flexible Coax Cable
HP/Agilent
Part Number
Qty Description
B1W1 ET/ES 2W (part of B1) 1 FAN (B1) to MOTHERBOARD (A17J5)
W13 ET/ES F 08753-60026 1 REFERENCE (A12J3) to RP
(EXT REF)
W21 ET/ES 14R 8120-6876 1 MOTHERBOARD (A17J12) to RP
(VGA OUT)
W27 ET/ES 34R 8120-6407 1 RP INTERFACE (A16J4) to
MOTHERBOARD (A17J6)
W28 ES 2W 85047-60005 1 RP INTERFACE (A16J10) to RP
(PORT 1 FUSE)
W29 ES 2W 85047-60005 1 RP INTERFACE (A16J11) to RP
(PORT 2 FUSE)
W30 ET/ES 1D5 3W 8120-6458 1 RP INTERFACE (A16J3) to
HIGH-STABILITY FREQ REF (A26J1)
W35 ET/ES 50R 8120-6379 1 CPU (A9J1) to MOTHERBOARD
(A17J7)
W36 ET/ES 26R 8120-6382 1 CPU (A9J2) to MOTHERBOARD
(A17J8)
