Agilent Technologies 8753ET Service Guide

13-12 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ES: Major Assemblies, Top
Ref.
Desig.
Option HP/Agilent
Part Number
Qty Description
A1, A2
NOT SHOWN
a
a. See “8753ET/ES: Front Panel Assembly, Inside” on page 13-38.
A3 08753-60231 1 ASSY-SOURCE 3 GHz (EXCHANGE: 08753-69231)
A3 006 08753-60146 1 ASSY-SOURCE 6 GHz (EXCHANGE: 08753-69146)
A4 08753-60907 1 ASSY-SAMPLER R
A5 08753-60908 1 ASSY-SAMPLER A
A6 08753-60908 1 ASSY-SAMPLER B
A7 08753-60164 1 BD ASSY-PULSE GENERATOR
A8
b
b. For fuse part numbers on the A8 Post Regulator, refer to “Miscellaneous” on page 13-59.
08753-60949 1 BD ASSY-POST REGULATOR
A9
NOT SHOWN
c
c. See “8753ES: Major Assemblies, Bottom” on page 13-15.
A10 08753-60958 1 BD ASSY-DIGITAL IF
A11 08753-60162 1 BD ASSY-PHASE LOCK
A12 08753-60957 1 BD ASSY-REFERENCE
A13 08753-60013 1 BD ASSY-FRAC N ANALOG
A14 08753-60068 1 BD ASSY-FRAC N DIGITAL
A15 0950-3488 1 ASSY-PREREGULATOR
A16
NOT SHOWN
d
d. See “8753ES: Rear Panel Assembly” on page 13-42.
A17
NOT SHOWN
e
e. See “8753ET/ES: Chassis Parts, Inside” on page 13-58.
A18
NOT SHOWN
a
A19 08753-60359 1 BD ASSY-GRAPHICS PROCESSOR (GSP) (under sheet
metal cover)
A20 0950-2782 1 ASSY-DISK DRIVE
A26 1D5
NOT SHOWN
f
f. See “8753ET/ES: Rear Panel Assembly, Option 1D5” on page 13-44.
A27
NOT SHOWN
a
B1
NOT SHOWN
d
RPG
NOT SHOWN
a
