13-42 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ES: Rear Panel Assembly
Ref.
Desig.
Opt
Type
a
a. nR = Ribbon Cable (n is the number of wires in the ribbon)
HP/Agilent
Part Number
Qty Description
1 34R 8120-6407 1 RP INTERFACE (A16J4) TO MB (A17J6) (W27)
2 85047-60005 2 FUSE HARNESS ASSEMBLY
3 (A16) 08720-60138 1 BD ASSY-REAR PANEL INTERFACE (A16)
4 08753-60026 1 ASSY-EXTERNAL REFERENCE CABLE (W13)
5 08415-60036 1 ASSY-FAN
6 1251-2942 4 FASTENER CONN RP LOCK
7 2190-0034 2 WASHER LK .194ID10
7 0380-0644 2 NUT STDF .327L 6-32
8 1251-7812 4 FASTENER CONN RP LOCK
9 0515-0379 4 SCREW SMM3.5X16 CWPNTX
9 3050-1192 4 FLAT WASHER
10 0515-0372 10 SCREW SMM3.0X8 CWPNTX
11 08720-00071 1 REAR PANEL SHEET METAL
12 3160-0281 1 FAN GUARD
13 6960-0419 1 HOLE PLUG
14 6960-0086 1 HOLE PLUG
15 2190-0102 8 WASHER LK .472ID
15 2950-0035 8 NUT HEX 15/32-32
16 0400-0271 1 GROMMET SN.5-515ID
17 2110-0047 2 FUSE
17 1400-0112 2 FUSE CAP
18 6960-0027 2 HOLE PLUG
19 1D5
HIGH STABILITY FREQUENCY REFERENCE
b
b. See “8753ET/ES: Rear Panel Assembly, Option 1D5” on page 13-44.
