Agilent Technologies 8753ET Service Guide

Chapter 4 4-19
Start Troubleshooting Here
Receiver (8753ET)
Receiver (8753ET)
Required Equipment
Observe the A and B Input Traces
A Input
1. Connect the short to the Reflection port.
2. Press
.
3. Observe the measurement trace displayed by the A input. The trace should have about
the same flatness as the trace in Figure 4-9.
B Input
1. Disconnect the short from the Reflection port and connect the through cable between
the Reflection and Transmission ports.
2. Press .
3. Observe the measurement trace displayed by the B input. The trace should have about
the same flatness as the trace in Figure 4-10.
Description HP/Agilent Part or Model Number
Short Part of 85032B Calibration Kit
Cable: 50Ω, Type-N 8120-4781
Preset Meas
INPUT PORTS
A
Scale Ref
AUTO SCALE
SCALE/DIV
1 x1
Meas
INPUT PORTS
B
