Agilent Technologies 8753ET Service Guide

2-50 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
9. Uncorrected Port Performance
The analyzer can perform error-correction and store the error coefficients. These error
coefficients are, in fact, measurements of the analyzer’s uncorrected port performance.
NOTE The crosstalk calibration coefficients are omitted in this procedure. They are
covered in the “Test Port Crosstalk” performance test.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Procedure
First Full 2-Port Calibration
1. Connect the equipment as shown in Figure 2-29.
Uncorrected
a
Error
Terms
a. At 25 °C ±5 °C, with less than 1 °C deviation from the measurement calibration
temperature.
Frequency Range
300 kHz to 1.3 GHz 1.3 GHz to 3 GHz
3 GHz to 6 GHz
b
b. Only for analyzers with Option 006.
Directivity 35 dB 30 dB 25 dB
Source Match 16 dB 16 dB 14 dB
Load Match 18 dB 16 dB 14 dB
Reflection Tracking ±1.0 dB ±1.0 dB ±1.5 dB
Transmission Tracking ±1.0 dB ±1.0 dB ±1.5 dB
Description HP/Agilent Part or Model Number
Calibration Kit: 7-mm 85031B
Cable, APC-7: 24-inch 8120-4779
Additional Equipment for 75Ω Analyzers
Calibration Kit: Type-N 85036B
Cable: 75Ω, Type-N, 24-inch 8120-2408
