Chapter 10 10-43
Service Key Menus and Error Messages
GPIB Service Mnemonic Definitions
Analog Bus Codes
ANAI[D] Measures and displays the analog input. The preset state input to
the analog bus is the rear panel AUX IN. The other 30 nodes may
be selected with
D only if the ABUS is enabled (ANABon).
OUTPCNTR Outputs the counter’s frequency data.
OUTPERRO Reads any prompt message sent to the error queue by a service
routine.
OUTPTESS Outputs the integer status of the test most recently executed.
Status codes are those listed under “TST?”.
TST? Executes the power-on self test (internal test 1) and outputs an
integer test status. Status codes are as follows:
0 =pass
1 =fail
2 =in progress
3 =not available
4 =not done
5 =done
