13-38 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ET/ES: Front Panel Assembly, Inside
Ref.
Desig.
Opt
Type
a
a. nR = Ribbon Cable (n is the number of wires in the ribbon)
HP/Agilent
Part Number
Qty Description
1 08753-00150 1 DISPLAY HOLD DOWN
2 2090-0386 1 DISPLAY LAMP
3 1000-0995 1 DISPLAY GLASS
7 1990-1864 1 RPG (INCLUDES CABLE AND
HARDWARE)
8 E4400-40003 1 RPG KNOB
9 08720-40016 1 FLUBBER KEYPAD
10 0515-0430 8 SCREW SM 3.0 6CWPNTX
11 0515-0665 4 SCREW SMM 3.0 14CWPNTX
12 1400-1439 2 CABLE CLIP
13 0515-0372 3 SCREW SMM 3.0 8CWPNTX
14 08753-60364 2 CABLE ASSY, PROBE POWER
14 2950-0144 2 NUT, HEX 3/8-32
15 08753-00112 1 PLATE, PROBE POWER
16 0515-0430 2 SCREW SMM 3.0 6CWPNTX
17 08753-20948 1 COVER, INVERTER
A1 08720-60267 1 BD ASSY-FRONT PANEL
A2 08753-60358 1 BD ASSY-FRONT PANEL INTERFACE
A18 08753-60937 1 LCD REPLACEMENT ASSY
A27 0950-3379 1 ASSY-INVERTER
A1W1 26R 8120-8439 1 A1 TO A2
W17 50R 8120-8431 1 A2 TO A17
W22 5R 8120-8842 1 CABLE-FP INTF (A2J7) to INVERTER (A27)
W23 31R 8120-8409 1 CABLE-FP INTF (A2J6) to DISPLAY (A18)
