2-108 Chapter 2
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
5. Reflection Test Port Output Power Linearity
(Analyzers with Option 004)
This test verifies the analyzer’s test port output power linearity throughout the analyzer’s
frequency range. A power meter calibration sets the reference output power across the
analyzer’s frequency range. The network analyzer’s B-channel receiver is used to
determine power linearity after each change in output power.
NOTE This test does not verify the functionality of the step attenuator. To verify its
function, perform “Step 2. Operator's Check” on page 4-6.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Procedure
Power Meter Calibration
1. Zero and calibrate the power meter for one or both sensors.
2. Connect the equipment as shown in Figure 2-61, using the 8482A power sensor.
Power Range
Power Level Linearity
a
a. Relative to 0 dBm from 300 kHz to 3 GHz
(6 GHz for Option 006).
−15 dBm to +5 dBm ± 0.2 dB
+5 to +10 dBm ± 0.5 dB
Description HP/Agilent Part or Model Number
Power Meter 437A/438A or E4418B/4419B
Power Sensor 8482A
Attenuator: 20 dB, Type-N 8491A Option 020
RF Cable: 50Ω, Type-N, 24 inch 8120-4781
Additional Equipment for Option 006 Analyzers
Power Sensor 8481A
To Next Page
