2-82 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Test Port 2 Input Worst-Case 3rd Harmonic
45.To change the stop frequency for measuring the receiver 3rd harmonic:
If you do not have Option 006, press .
If you have Option 006, press .
46.Press .
47.After one sweep, press to normalize the
trace.
48.Press to get a better viewing of the trace.
49.Press .
50.After one sweep, press .
51.Press .
52.Write the marker 1 value on the performance test record.
Stop 1 G/n
Stop 2 G/n
System
HARMONIC MEAS
HARMONIC OFF
Display
DATA
→
MEMORY
DATA/MEM
Scale Ref
AUTO SCALE
System
HARMONIC MEAS
HARMONIC THIRD
Scale Ref
AUTO SCALE
Marker Search
SEARCH:MAX
