Chapter 2 2-121
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
17.Convert the measured linear magnitude mean value to log magnitude, using this
equation.
Power(dBm)= 20 × [log
10
(linear magnitude mean value)]
18.Write this calculated value on the performance test record.
Transmission Test Port Input Noise Floor Level from 3 GHz to 6 GHz
(IF BW = 3 kHz) Option 006 Only
19.Press .
20.Press .
21.When the analyzer finishes the sweep, read the mean value.
22.Convert the measured linear magnitude mean value to log magnitude, using this
equation.
Power(dBm)= 20 × [log
10
(linear magnitude mean value)]
23.Write this calculated value on the performance test record.
In Case of Difficulty
1. Perform “ADC Offset Correction Constants (Test 52)” on page 3-15.
2. Repeat this performance test.
3. Refer to Chapter 8 , “Receiver Troubleshooting,” for more troubleshooting information.
Avg
3 k/m
