Agilent Technologies 8753ET Service Guide

Chapter 1 1-5
Service Equipment and Analyzer Options
Required Tools and Equipment
Table 1-2 Agilent 8753ES Service Test Equipment
Required Equipment Critical Specifications HP/Agilent
Recommended Model
Use
a
Frequency Counter Frequency: 300 kHz–3 GHz (6 GHz
for Option 006)
5350B/51B/52B P
Spectrum Analyzer Freq. Accuracy ±7 Hz 8563E A
Synthesized Sweeper Maximum spurious input: <−30 dB
Residual FM: <20 kHz
83620A Option 001 or
83712B Option 1E1
P
Oscilloscope Bandwidth: 100 MHz
Accuracy: 10%
any T
Digital Voltmeter Resolution: 10 mV any T
Tool Kit No substitute 08753-60023 T
Power Meter (GPIB) 436A/437B/438A or
E4418A/E4419A
A, P, T
Power Sensor Frequency: 300 kHz–3 GHz, 50Ω 8482A A, P, T
Power Sensor
(for Option 006)
Frequency: 3 GHz–6 GHz 8481A A, P, T
Power Sensor
(for Option 075)
Frequency: 300 kHz–3 GHz, 75Ω 8483A Opt. H03 A, P
Photometer Tektronix J16 A
Photometer Probe Tektronix J6503 A
Light Occluder Tektronix 016-0305-00 A
Printer HP ThinkJet, DeskJet,
LaserJet
P
Floppy Disk one 3.5-inch formatted 1.44 MB any A
Calibration Kit 7 mm, 50Ω No substitute 85031B P
Calibration Kit Type-N,
75Ω (for Option 075)
No substitute 85036B P
Verification Kit 7 mm No substitute 85029B P
Low Pass Filter >50 dB @ 2.96 Hz and passband
that includes 800 MHz
9135-0198 A
Step Attenuator No substitute 8496A Opt. 003, H18 P
Fixed Attenuator (2) Return loss: ≥32 dB APC-7 20 dB 8492A Opt. 020 P, T
Fixed Attenuator (2) Type-N 20 dB 8491A Opt. 020 P, T
Power Splitter, 2-way Type-N 11667A, Opt. 001 P
Minimum Loss Pad (2)
(for ES Option 075)
Type-N, 50Ω to 75Ω 11852B A, P, T
Adapter APC-7 to Type-N (f) 11524A A, P
