2-174 Chapter 2
System Verification and Performance Tests
Agilent 8753ET Performance Test Records
Agilent Technologies Company
Model 8753ET
Serial Number
Report Number
Option(s) Date
10. Uncorrected Port Performance (continued)
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
Test Description Frequency Range Spec.
(dB)
Measured Value
(dB)
Meas. Uncert.
(dB)
Forward Direction
Refl. Tracking 300 kHz to 1.3 GHz ± 1.0 ± 0.009
Refl. Tracking 1.3 GHz to 3 GHz ± 1.0 ± 0.019
Refl. Tracking 3 GHz to 6 GHz ± 2.0 ± 0.030
Forward Direction
Load Match 300 kHz to 1.3 GHz ≤ −24 ± 0.2
Load Match 1.3 GHz to 3 GHz ≤ −19 ± 0.2
Load Match 3 GHz to 6 GHz ≤ −16 ± 0.2
Forward Direction
Trans. Tracking 300 kHz to 1.3 GHz ± 1.5 ± 0.006
Trans. Tracking 1.3 GHz to 3 GHz ± 1.5 ± 0.055
Trans. Tracking 3 GHz to 6 GHz ± 2.5 ± 0.054
