Chapter 3 3-37
Adjustments and Correction Constants
Loading Firmware
In Case of Difficulty
If the firmware did not load successfully, LED patterns on the front panel can help you
isolate the problem.
If the following LED pattern is present, an acceptable firmware filename was not found
on the disk. (The desired format for firmware filenames is 8753Ex_7._yz, where x =
either S or T, and where yz = the latest firmware revision number.) Check that the
firmware disk used was for the 8753ET/ES.
If any of the following LED patterns are present, the firmware disk may be defective.
If any other LED pattern is present, the CPU board is defective.
LED Pattern
CH1 CH2 R L T S
✲✲
LED Pattern
CH1 CH2 R L T S
✲✲
✲✲
✲✲✲
✲✲
✲✲
✲✲
✲✲
✲✲✲
✲✲
✲✲
✲✲
