13-62 Chapter 13

Replaceable Parts

Replaceable Part Listings

Table 13-1 Abbreviation Definitions

REFERENCE DESIGNATIONS LED........................................light-emitting diode

A................................................................Assembly M...............................................................meters

B...............................................................fan; motor M...............................................meteric hardware

J..........electrical connector (stationary portion); jack MB.......................................................motherboard

RPG.........................................rotary pulse generator MHz........................................................megahertz

W................................cable; transmission path; wire mm.....................................................millimeters

ABBREVIATIONS MON........................................................monitor

A.......................................................................ampere NOM.......................................................nominal

ALC.......................................automatic level control NY...............................................................nylon

ASSY..........................................................assembly OD...............................................outside diameter

AUX............................................................auxiliary Opt..............................................................option

BD.......................................................................board OSC........................................................oscillator

COAX.............................................................coaxial PC..........................................................patch lock

CPU.......................................central processing unit PC....................................................printed circuit

CW........................................conical washer (screws) PN...............................................panhead (screws)

D................................................................diameter REF........................................................reference

ESD........................................electrostatic discharge REPL.................................................replacement

EXT.............................................................external RP.........................................................rear panel

EYO.....................................................YIG oscillator SH....................................socket head cap (screws)

FL...................................................flathead (screws) TX........................................TORX recess (screws)

FP............................................................front panel Qty...........................................................quantity

FRAC-N..................................................fractional N V.....................................................................volt

FREQ........................................................frequency WFR......................................................wire formed

GHz...........................................................gigahertz W/O..........................................................without

GPIB............................general purpose interface bus YIG..........................................yttrium-iron garnet

HEX..........................................................hexagonal OPTIONS

HP..................................................Hewlett-Packard 002..................................harmonics measurement

HX...............................................hex recess (screws) 004.........................55dB step attenuator (ET only)

ID......................................................inside diameter 006.................................................6 GHz operation

IF..........................................intermediate frequency 010.....................................................time domain

I/O.........................................................input/output 011.........................................w/o test set (ES only)

kHz............................................................kilahertz 075...................................75 ohm test set (ES only)

LCD...........................................liquid crystal display 1D5........................................10 MHz precision ref
