Chapter 14 14-13
Assembly Replacement and Post-Repair Procedures
Display, Display Lamp and Inverter Assemblies (A18, A27)
CAUTION Be sure that cables are plugged in square and correct. Failure to do so will
result in serious component damage.
CAUTION Do not exceed 10 in-lb when replacing the display hold-down plate screws.
Figure 14-5 Display, Display Lamp and Inverter Assemblies
