180 Chapter5
Language Reference
CALCulate Subsystem
Example: To query the mean power of a set of GSM bursts:
1. Set the waveform measurement sweep time to
acquire the required number of bursts.
2. Set the triggers such that acquisition happens at a
known position relative to a burst.
3. Then query the mean burst levels using,
CALC:DATA2:COMP? MEAN,62,1315,1442.3 (These
parameter values correspond to GSM signals.)
Remarks: The optional parameters must be entered in the
specified order. If you want to specify <length>, you
must also specify <soffset> or its default. For example:
CALC:DATA2:COMP? MEAN,62,1315
CALC:DATA2:COMP? MEAN,DEFault,1315
This command uses the data setting specified by the
FORMat:DATA command and can return binary or
ascii data.
History: Added in revision A.03.00 and later
Measurement Available Traces
Markers
Available?
ACP - adjacent channel power
(Basic, cdmaOne, cdma2000, W-CDMA
(3GPP), W-CDMA (Trial & Arib),
iDEN, NADC, PDC modes)
no traces no markers
BER - bit error rate
(iDEN mode)
no traces no markers
CDPower - code domain power
(cdmaOne mode)
POWer (n=2)
a
TIMing (n=3)
a
PHASe (n=4)
a
yes
CDPower - code domain power
(cdma2000, W-CDMA (3GPP) modes)
CDPower (n=2)
a
EVM (n=5)
a
MERRor (n=6)
a
PERRor (n=7)
a
SPOWer (n=9)
a
CPOWer (n=10)
a
yes
